Multi-OS TV Box, Khadas VIM1S single board computer Amlogic S905Y4 2GB 16GB Support 2.4G/5G WiFi Bluetooth 5.0, Multi-Video Decoder, Streaming Media Player HD/4K/HDR, UHS-I TF Card Extension

From the brand

Single Board Computers

Single Board Computer-VIMs

Mind Portable Workstation

Mind Family-Mini Computer

Single Board Computer-Edges

Single Board Computer-Edges

Portable Headphone Amplifier

Hi-Fi DAC& Amplifier

Hi- Fi DAC & Amplifier

VIM1S is equipped with a high-performance SOC from Amlogic – S905Y4, RAM: 2GB LPDDR4 at 1176MHz, 32Bit; Storage: 16GB eMMC 5.0，2.0GHz Quad core Cortex-A35 CPU，Integrated with ARM Mali-G31 MP2 GPU up to 850MHz,Support multi-video decoder up to 4x1080P @60fps, 4K@60fps H.265 decoder. Supports HDR10, HDR10+, HLG HDR video processing.
Flexible Connectivity: Wifi5 AP6256 Module 802.11ac/a/b/g/n, Bluetooth 5.0, 10/100M LAN
Maker Friendly :VIN-port, Programmable MCU, 40-Pin 2.54mm Header/30-pin 1.0mmFPC Connector, x3 user buttons, hardware encryption .
Rich I/O: x2 (500mA) USB 2.0 HOSTs, x1 USB Type-C (USB2.0 OTG & 5V DC IN)
UHS-I TF Card Extension (256GB Max) via the onboard Molex Slot.
RTC (real time clock) via the RTC Battery Port (0.8mm Pitch Header).
IR Receiver (Dual Channels)
With the built-in OOWOW embedded service, VIM1S includes a graphical interface for online OS download and installation. Easily install Android, Ubuntu, and many other operating systems in just a few steps, without having to read complex technical manuals!
